Matrični preklopnik Aten VM6404HB
Šifra proizvoda: 39660, stanje skladišta: na upit
  1. 4K HDMI 2.2 matrični HDMI preklopnik
  2. Ugrađen scaler i funkcija video zida

4K HDMI 2.2, matrični HDMI preklopnik bez zadrške (seamless switch), ugrađen scaler i funkcija video zida, audio breakout, kontrola glasnoće pojedinog HDMI izlaza, Ulazi: 4x HDMI 2.2, Izlazi: 4x HDMI 2.2, 1x Audio, Propusnost: 10.2 Gbps (3.40 Gbps po liniji), Kontrola putem RS232/IR/WEB-GUI, Tezina: 7 Kg

4 x 4 HDMI input/output connections
Multiple means for system configuration including front-panel pushbuttons, IR, RS-232 control, and Ethernet connections for web GUI or Telnet
4K Scaler – features a 4K video scaling function to convert input resolutions to the display’s native resolutions
Seamless Switch™ – features close-to-zero second switching for continuous video streams, real-time switching, and stable signal transmissions*
Video wall – allows you to create custom video wall layouts via intuitive web GUI*
EDID Expert – selects optimum EDID settings for smooth power-up, high-quality display, and use of the best resolutions across different screens
4K Video Wall using Lower-Resolution Displays – split a 4K signal to four 1080p displays to form a 2x2 4K video wall
FrameSync – prevents image tearing by synchronizing the scaler output frame rate to the input signal frame rate
HDMI (3D, Deep color, 4K); HDCP 2.2 compatible
Consumer Electronics Control (CEC) supported*
ESD protection for HDMI
Rack mountable (1U design)


 Proizvođač Aten
 Tip Matrični HDMI preklopnik
 Ulazi 4x HDMI 2.2
 Izlazi 4x HDMI 2.2, 1x Audio
 Propusnost 10.2 Gbps (3.40 Gbps per lane)
 Podržani signali do 4K, 4096x2160/3840x2160 @60Hz (4:2:0); 4096x2160/3840x2160 @30Hz (4:4:4)
 Kontrola EDID, IR, RS232, WEB-GUI
 Snaga -
 Napajanje AC220V:78.1W:366BTU
 Dimenzije        432x44x307 mm
 Težina 4,72 Kg
 Jamstvo 2 godine
Redovna cijena
Cijena bez PDV: na upit
Cijena sa PDV: na upit
Odobravamo
popuste za obrazovne i neprofitne organizacije
popuste na veću koliĉinu
popuste za daljnju prodaju
